Essential

Features

  • Full table base (add your own work surface)
  • Meets BIFMA X5.5 standards
  • UL 962 approved
  • Easy-order with one part number

When a table with all the added-value features isn’t necessary and you need just the essentials, you need OMT-Veyhl’s Essential height-adjustable table base. This ergonomic option is available in black, white, or silver. Essential is a lower cost table base with the same high-quality production.



Spec Sheet

User Guide

Troubleshooting

Parts Diagram

Assembly How-To Video



Are you a distributor?

Request Pricing Category:
  • Single stage height range 26″−45″ (without top)
  • Dual stage height range 21.75″-47.75″ (without top)
  • Fits both 24″ and 30″ tops
  • Standard base widths 48″−72″ (anti-sag bar recommended for widths over 60″)
  • Raise/lower speed of 1.375″ per second
  • Power consumption <0.3W
  • Ships complete, just attach base to top
  • Available in black, white or silver



PRODUCT CARE & CLEANING
Do not use any abrasive or acidic cleaning solutions. No harsh chemicals including lye or rust remover.

Powder Coat Surfaces
For Simple Cleaning: general household cleaners are safe on all powder coated surfaces
For Disinfecting*: Use a 1:10 bleach + water dilute or a 70% Isopropyl alcohol + water dilute
Any residue should remove easily with soap and water.

Laminate Work Surfaces
For Simple Cleaning:
 Damp cloth or sponge with a mild soap or detergent
For Disinfecting*: Use a 1:3 bleach + water dilute or a 70% Isopropyl alcohol + water dilute
Rinse with a damp cloth.

*Be sure to dilute to recommended instructions. Test all cleaners in an inconspicuous area to verify.



WARRANTY INFORMATION
Three Years: Electronic components such as control boxes, handswitches, motors.
Five Years: Mechanical components such as crank drives, spindles.
Ten Years: Structural components such as beams, feet and top supports.

Handswitch Options







Foot Options





Color Options





TypeStroke Length (IN)Height Min/Max (IN)Travel Speed (IN/Sec)Max Rated Load (LB)Noise Level (DB)
Single Stage1926/451.375250<50
Dual Stage2621.75/47.751.375250<50

DRAWING

Standard Dimensions

  • Base depth: 22.75″
  • Base width: 48″–72″
  • Base height: SSE: 26″–45″
    DSL: 21.75″–47.75″
  • Column dimensions: SSE: 3.35″ x 2.17″
    DSL: 3.54″ x 2.36″
  • Max load: Rated load (including table top): 250 lb.
    Functional load: 306 lb.
  • Anti-sag bar available for widths over 60″
